产品参数
|
VCXO 3225 项目类型Item / Type |
目录Content |
Units |
|
|
1 |
输出类型Output Type |
CMOS |
- |
|
2 |
输出负载Output Load |
15～30 |
pF |
|
3 |
振动方式Oscillation Mode |
Fundamental |
- |
|
4 |
电源电压Supply Voltage |
1.8 3.3 5 |
V |
|
5 |
频率范围Frequency Range |
1.000～54.000 |
MHz |
|
6 |
工作温度Operating Temperature Range |
-10～+70 , - 40～+85 |
℃ |
|
7 |
储存温度Storage Temperature Range |
- 55～ +125 |
℃ |
|
8 |
电压Voltage Vol ( Max.) / Voh ( Min.) |
0.1 VDD / 0.9 VDD |
V |
|
9 |
上升(Tr) /下降(Tf)延Rise ( Tr ) / Fall ( Tf ) Time |
5 Max. |
ns |
|
10 |
电源电流Supply Current |
45 Max. |
mA |
|
11 |
对称性Symmetry |
45～ 55 |
% |
|
12 |
启动时间Start-up Time |
10 Max. |
ms |
|
13 |
频率牵引范围Frequency Pulling Range |
±50 , ±100 or specify. |
ppm |
|
14 |
控制电压Nominal Control Voltage |
0.5 VDD |
V |
|
15 |
控制电压范围Control Voltage Range |
0～VDD |
V |
|
16 |
线性度Linearity |
±10 Max. |
% |
|
17 |
相位抖动Phase Jitter ( 12 KHz ～ 20 MHz ) |
1 Max. |
ps |
|
18 |
老化率Aging ( at 25℃ ) |
±3 Max |
ppm / year |
